Camera Profiles

Introduced 1989

Type:

6x7 format Single-Lens-Reflex camera

Film:

120 type roll film (10 exposures)

220 type roll film (20 exposures)

Picture Size:

55mm x 70mm

Lens Mount:

Pentax 67 double bayonet mount system

(Inner bayonet and Outer bayonet)

Shutter:

Electronically controlled focal plane shutter

Viewfinder:

Four types interchangeable viewfinders (Option)

Field of View: Body-100%, Eye-level type (TTL Pentaprism, Pentaprism)- Approx. 90%, Magnification-1.0x, Diopter– -1D

Focusing Screen:

Microprism type (Interchangeable)

Mirror:

Swing-up-and-back instant return mirror, with lock-up device

Film Winding:

With rapid wind lever (180 degree angle)

Exposure Counter:

Automatic reset exposure counter

Flash Synchronization:

FP and X terminals

Electronic flash at 1/30- 1 sec., B

Power Source:

6V Alkaline or Silver-oxide battery

(4LR44/A544, 4SR44/544/PX28)

Size and weight:

Body only-177(W) x 101(H) x 91(D) mm

{7.0” x 4.0” x 3.6”} 1.29kg {2.8 lb}

With TTL Pentaprism-177(W) x 150(H) x 91(D)mm

{7.0” x 5.9” x 3.6”} 1.81kg {4.0lb}

Accessories:

Body mount cap, Finder cap, Strap, Spool, Shutter cocking key and battery

Information from Pentax 67 manual
